Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 272
272
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
17
Line to Line Under-Voltage condition detected
18
Line to Line Over-Voltage condition detected
19
Phase to phase voltage imbalance detected
20
The unit detects the supply voltage phases are rotated
21
Line voltage frequency is below the warning level
22
Line voltage frequency has exceeded warning level
33
Total Real Power (kW)is below warning level
34
Total Real Power (kW)has exceeded warning level
35
Under Reactive Power Consumed (+kVAR) condition detected
36
Over Reactive Power Consumed (+kVAR) condition detected
37
Under Reactive Power Generated (-kVAR) condition detected
38
Over Reactive Power Generated (-kVAR) condition detected
39
Total Apparent Power (kVA) is below warning level
40
Total Apparent Power (kVA) exceeded warning level
41
Under Total Power Factor Lagging (-PF) condition detected
42
Over Total Power Factor Lagging (-PF) condition detected
43
Under Total Power Factor Leading (+PF) condition detected
44
Over Total Power Factor Leading (+PF) condition detected
50
PTC input indicates that the motor stator windings overheated
51
DeviceLogix defined warning was generated
56
Invalid parameter config. See parameters 38-39 for details
58
DeviceLogix Feedback Timeout Trip was detected
60
Number of Starts Warning Level Exceeded
61
Operating Hours Warning Level Exceeded
65
Input Channel 00 on Analog Module 1 exceeded its Warning Level
66
Input Channel 01 on Analog Module 1 exceeded its Warning Level
67
Input Channel 02 on Analog Module 1 exceeded its Warning Level
68
Input Channel 00 on Analog Module 2 exceeded its Warning Level
69
Input Channel 01 on Analog Module 2 exceeded its Warning Level
70
Input Channel 02 on Analog Module 2 exceeded its Warning Level
71
Input Channel 00 on Analog Module 3 exceeded its Warning Level
72
Input Channel 01 on Analog Module 3 exceeded its Warning Level
73
Input Channel 02 on Analog Module 3 exceeded its Warning Level
74
Input Channel 00 on Analog Module 4 exceeded its Warning Level
75
Input Channel 01 on Analog Module 4 exceeded its Warning Level
76
Input Channel 02 on Analog Module 4 exceeded its Warning Level
81
Digital Expansion Module 1 is not operating properly
82
Digital Expansion Module 2 is not operating properly
83
Digital Expansion Module 3 is not operating properly
84
Digital Expansion Module 4 is not operating properly
85
Analog Expansion Module 1 is not operating properly
86
Analog Expansion Module 2 is not operating properly
87
Analog Expansion Module 3 is not operating properly
Warning History Code Description
