Appendix A Specifications
Table 351 - Temperature Derating
Electromagnetic
Compatibility Specifications
➊Performance Criteria 1 requires the DUT to experience no degradation or loss of performance.
➋Environment 2.
Control Module
Voltage
Relay 0
Current
Relay 1
Current
Relay 2
Current
Number of
Digital Inputs
Active
Operating Temperature
Range
Open Application
120/240V AC
1.0 A
1.0 A
1.0 A
4
-20…+55 °C (-4…+131 °F)
5.0 A
1.0 A
1.0 A
4
-20…+50 °C (-4…+122 °F)
24V DC
0.2 A
0.2 A
0.2 A
4
-20…+55 °C (-4…+131 °F)
0.2 A
0.2 A
0.2 A
6
-20…+50 °C (-4…+122 °F)
5.0 A
1.0 A
1.0 A
6
-20…+30 °C (-4…+86 °F)
Enclosed
Application
120/240V AC
5.0 A
5.0 A
5.0 A
4
-20…+40 °C (-4…+104 °F)
24V DC
0.2 A
0.2 A
0.2 A
4
-20…+40 °C (-4…+104 °F)
5.0 A
1.0 A
1.0 A
6
-20…+30 °C (-4…+86 °F)
Table 352 - Electromagnetic Compatibility Specifications
Electrostatic Discharge Immunity
Test Level:
Performance Criteria:
8kV Air Discharge
6kV Contact Discharge
1
➊➋
RF Immunity
Test Level:
Performance Criteria:
10V/m
1
➊➋
Electrical Fast Transient/Burst Immunity
Test Level:
Performance Criteria:
4kV (Power)
2kV (Control & Comm)
1
➊➋
Surge Immunity
Test Level:
Performance Criteria:
2kV (L-E)
1kV (L-L)
1
➊➋
Radiated Emissions
Class A
Conducted Emissions
Class A
