Protection
Table 353 - Protection
Trip Warning
Overload Yes
Yes
Phase Loss
Yes
No
Ground Fault
➊
Yes Yes
Stall Yes
No
Jam Yes
Yes
Underload Yes
Yes
Thermistor (PTC)
Yes
Yes
Current Imbalance
Yes
Yes
Communication Fault
Yes
Yes
Communication Idle
Yes
Yes
Remote Trip
Yes
No
Blocked Start/Start Inhibit
Yes
No
Under Voltage L-L
Yes
Yes
Over Voltage L-L
Yes
Yes
Voltage Unbalance
Yes
Yes
Phase Rotation
Yes
Yes
Under Frequency
Yes
Yes
Over Frequency
Yes
Yes
Under Real Power (kW)
Yes
Yes
Over Real Power (kW)
Yes
Yes
Under Reactive Power Consumed (+kVAR)
Yes
Yes
Over Reactive Power Consumed (+kVAR)
Yes
Yes
Under Reactive Power Generated (-kVAR)
Yes
Yes
Over Reactive Power Generated (-kVAR)
Yes
Yes
Under Apparent Power (kVA)
Yes
Yes
Over Apparent Power (kVA)
Yes
Yes
Under Power Factor Lagging (-PF)
Yes
Yes
Over Power Factor Lagging (-PF)
Yes
Yes
Under Power Factor Leading (+PF)
Yes
Yes
Over Power Factor Leading (+PF)
Yes
Yes
Power Value Overflow (kW, kVAR or KVA)
Yes
Yes
Table 354 - Overload Protection
Type of Relay
Ambient Compensated Time-Delay
Phase Loss Sensitive
Nature of Relay
Solid-State
FLA Setting
See
Full Load Amps Setting on page 81
Trip Rating
120% FLA
Trip Class
5…30
Reset Mode
Automatic or Manual
Overload Reset Level
1…100% TCU
