42 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 2 Installation and Wiring
Table 8 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with Bul.
100-C and 100-D IEC contactors protected by fuses
Table 9 - Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with Bul. 100-C IEC
contactors protected by Bul. 140U-D circuit breakers
Table 10 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with
Bul. 500 line NEMA contactors protected by fuses
Fuse Coordination The following tables list Type I and Type II Fuse Coordination when used in
conjunction with Bulletin 100-C & 100-D and Bulletin 500 NEMA Size 00… 2
Contactors.
Overload Relay using
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC[A]
Max. Available Fault
Current [A]
Max. Voltage [V] Class C or JJ fuse [A]
193-ESM-___-30A-C23
100-C09 9
100,000 600
20
100-C12 12 20
100-C16 16 30
100-C23 23 30
193-ESM-___-30A-C55,

193-ESM-___-60A-C55
100-C30 30 50
100-C37 37 50
100-C43 43 70
100-C55 55 80
Overload Relay using
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC[A]
Max. Available Fault
Current [A]
Max. Voltage [V]
Max. Circuit Breaker
Cat. No. 140U-D6D3-
193-ESM-___-30A-C23
100-C09 9
65,000 480Y/277V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23
100-C09 9
35,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23
100-C09 9
5,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
Overload Relay using Sensing Module
Cat. No.
Contactor Size Max. Starter FLC[A]
Max. Available Fault
Current [A]
Max. Voltage
[V]
Max. UL Fuse [A]
R J
592-ESM-___-30A-S2 00 9
100,000
600 — 20
592-ESM-___-30A-S2 0 18
240 30 30
600 30 30
592-ESM-___-30A-S2 1 27
240 60 100
600 30 50
592-ESM-___-60A-S2 2 45
240 100 200
600 60 100
ATTENTION: Select the motor branch circuit protection that complies with the
NEC and any other governing regional or local codes.
