358

Rockwell Automation Publication 193-UM015B-EN-P - November 2013

Appendix B Parameter List

Diagnostic
Display Setup
(Continued)

435

Screen4Param2

Parameter to display on Operator
Station Startup screen 4 line 2

UINT

2

1

0

560

39

436

DisplayTimeout

Inactivity time for a Diagnostic
Station

UINT

2

1

0

65535

300

Analog1 Setup

437

InAnMod1Ch00Type

Assignment for Analog Module 1
Input Channel 00 function

USINT

1

1

0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm

0

438

InAMod1Ch0Format

Assignment for Analog Module 1
Input Channel 00 Data Format

USINT

1

1

0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID

0

439

InAMod1C0TmpUnit

Assignment for Analog Module 1
Input Channel 00 Temperature
Units

USINT

1

1

0=DegreesC
1=DegreesF

0

440

InAMod1C0FiltFrq

Assignment for Analog Module 1
Input Channel 00 Filter Freq

USINT

1

1

0=17Hz
1=4Hz
2=62Hz
3=470Hz

0

441

InAMod1C0OpCktSt

Indicates Analog Module 1 Input
Channel 00 Open Circuit State

USINT

1

1

0=Upscale
1=Downscale
2=Zero

0

442

InAnMod1Ch0RTDEn

Enable Analog Module 1 Input
Channel 00 to function with RTD

BOOL

1

1

0=3-wire
1=2-wire

0

443

InAMod1C0TripDly

Analog Module 1 Input Channel
00 Trip Delay

USINT

1

10

0

250

10

Sec

444

InAMod1C0TripLvl

Level (in selected Units) where
Analog Input generates a trip

UINT

2

1

0

65535

0

445

InAMod1C0WarnLvl

Level (in selected Units) where
Analog Input generates a
warning

UINT

2

1

0

65535

0

Group

Param

No.

Parameter Name

Description

Type

Data Size

(bytes)

Scale

Factor

Min

Max

Default Units
