Chapter 7 Metering and Diagnostics
Device Status 0
Device Status 0 (Parameter 20) reports the general status of the E300 Electronic
Overload Relay and the sensing capabilities that are present.
Table 226 - Device Status 0 (Parameter 20)
Device Status 0 bit 14, "Ready", is cleared under the following circumstances:
•
Device Status 0 bit 0, "Trip Present", is set
•
The E300 Electronic Overload Relay has not completed its power up
initialization
•
The processing of data in a configuration assembly is in progress
•
A CopyCat function is in progress
•
A Factory Defaults command has been invoked and is in progress.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Trip Present
X
Warning Present
X
Invalid Configuration
X
Current Present
X
Ground Fault Current Present
X
Voltage Present
X
Emergency Start Enabled
X
DeviceLogix Enabled
X
Feedback Timeout Enabled
X
Operator Station Present
X
Voltage Sensing Present
X
Internal Ground Fault Sensing Present
X
External Ground Fault Sensing Present
X
PTC Sensing Present
X
Ready
Reserved
