404 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Appendix C EtherNet/IP Information
The following services are implemented for the Electrical Energy Object.
Table 417 - Electrical Energy Object Common Services
The following table describes the Get_Attributes_All response.
Table 418 - Electrical Energy Object Class Attributes Get_Attributes_All Response
23 Get
Percent Voltage
Unbalance
REAL Param 61 value converted to a REAL
24 Get L1 Real Power REAL Param 64 value converted to a REAL
25 Get L2 Real Power REAL Param 65 value converted to a REAL
26 Get L3 Real Power REAL Param 66 value converted to a REAL
27 Get Total Real Power REAL Param 67 value converted to a REAL
28 Get L1 Reactive Power REAL Param 68 value converted to a REAL
29 Get L2 Reactive Power REAL Param 68 value converted to a REAL
30 Get L3 Reactive Power REAL Param 70 value converted to a REAL
31 Get Total Reactive Power REAL Param 71 value converted to a REAL
32 Get L1 Apparent Power REAL Param 72 value converted to a REAL
33 Get L2 Apparent Power REAL Param 73 value converted to a REAL
34 Get L3 Apparent Power REAL Param 74 value converted to a REAL
35 Get Total Apparent Power REAL Param 75 value converted to a REAL
36 Get L1 True Power Factor REAL Param 76 value converted to a REAL
37 Get L2 True Power Factor REAL Param 77 value converted to a REAL
38 Get L3 True Power Factor REAL Param 78 value converted to a REAL
39 Get
Three Phase True Power
Factor
REAL Param 79 value converted to a REAL
40 Get Phase Rotation UINT Param 63 value
41 Get
Associated Energy
Object Path STRUCT of UINT
Padded EPATH
03 00 21 00 4E 00 24 01
Service Code
Implemented for:
Service Name
Class Instance
0x01 No Yes GetAttributes_All
0x0E No Yes Get_Attribute_Single
Attribute ID Data Type Name Value
1 Array[5] of INT Real Energy Consumed Odometer Attribute 1 Value
2 Array[5] of INT Real Energy Generated Odometer 0.0.0.0.0
3 Array[5] of INT Real Energy Net Odometer Attribute 3 Value
4 Array[5] of INT
Reactive Energy Consumed
Odometer
Attribute 4 Value
5 Array[5] of INT
Reactive Energy Generated
Odometer
Attribute 5 Value
6 Array[5] of INT Reactive Energy Net Odometer Attribute 6 Value
7 Array[5] of INT Apparent Energy Odometer Attribute 7 Value
8 Array[5] of INT 0.0.0.0.0
9 REAL Line Frequency Attribute 9 Value
10 REAL L1 Current Attribute 10 Value
11 REAL L2 Current Attribute 11 Value
12 REAL L3 Current Attribute 12 Value
13 REAL Average Current Attribute 13 Value
14 REAL Percent Current Unbalance Attribute 14 Value
Attribute ID Access Rule Name Data Type Value
