Rockwell Automation Publication 193-UM015B-EN-P - June 2014

47

Installation and Wiring Chapter 2

Table 16 - Voltage Mode (Parameter 352)

Potential (Voltage) Transformer Ratio

The E300 Electronic Overload Relay sensing module catalog number 193-ESM-
VIG-30A-CT can be used with step down potential (voltage) transformers. PT
Primary (Parameter 353) and PT Secondary (Parameter 354) allows the user to
identify the turns ratio of the step down potential (voltage) transformers in use.
The E300 Electronic Overload Relay will automatically adjust the measured
voltage based on these two configuration parameters. Users will use the primary
voltage for their voltage protection settings.

Table 17 - PT Primary (Parameter 353)

Table 18 - PT Secondary (Parameter 354)

Default Value

0 = Delta direct or with PTs

Range

0 = Delta direct or with PTs

1 = Wye direct or with PTs

2 = Delta with Delta to Wye PTs

3 = Wye with Delta to Wye PTs

4 = Delta with Wye to Delta PTs

5 = Wye with Wye to Delta PTs

Parameter Type

USINT

Size (Bytes)

1

Scaling Factor

1

Units

Default Value

480

Minimum Value

1

Maximum Value

65535

Parameter Type

UINT

Size (Bytes)

2

Scaling Factor

1

Units

Amps

Default Value

480

Minimum Value

165535

Maximum Value

Parameter Type

UINT

Size (Bytes)

2

Scaling Factor

1

Units

Amps
