Rockwell Automation Publication 193-UM015B-EN-P - June 2014 205
Protective Trip and Warning Functions Chapter 5
Configuration Trip
Refer to Invalid Configuration Mode in Chapter 3 for more information on
Configuration Trip.
Option Match
Refer to Option Match in Chapter 3 for more information on Option Match
Trip and Warning.
Expansion Bus Fault
Refer to Expansion Bus Fault in Chapter 3 for more information on Expansion
Bus Trip and Warning.
Non-Volatile Storage Fault
The E300 Electronic Overload Relay continuously monitors the status of its non-
volatile storage. The E300 Electronic Overload Relay will issue a non-volatile
storage fault trip if there is an issue with its non-volatile storage or if it becomes
corrupt. The Non-Volatile Storage Fault Trip is always enabled.
IMPORTANT The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
