Expansion analog module – Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 38
38
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 2 Installation and Wiring
Figure 28 - E300 Expansion Digital Module Wiring Diagram
Expansion Analog Module
Figure 29 - E300 Expansion Analog Module Terminal Designations
R04 R14 RC3
IN0
INC
IN1 IN2
IN3
Source
+
-
IN1+ IN1- RS1
IN2+ IN2- RS2
OUT+OUT-
IN0+ IN0- RS0
