Kvarh net 103, Kvarh net 100, Kvarh net 10-3 – Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 261: Kvarh net 103 kvarh net 100 kvarh net 10-3, Kvarh net 10
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
261
Metering and Diagnostics Chapter 7
kVARh Net 10
3
kVARh Net 10
3
(Parameter 97) reports a component of total reactive energy net
(kVARh). Multiply this value by 10
3
and add to the other kVARh Net
parameters.
Represents
000,000,XXX,000.000 kVARh
Table 302 - kVARh Net x 10E3 (Parameter 97)
kVARh Net 10
0
kVARh Net 10
0
(Parameter 98) reports a component of total reactive energy net
(kVARh). Multiply this value by 10
0
and add to the other kVARh Net
parameters.
Represents
000,000,000,XXX.000 kVARh
Table 303 - kVARh Net x 10E0 (Parameter 98)
kVARh Net 10
-3
kVARh Net 10
-3
(Parameter 99) reports a component of total reactive energy net
(kVARh). Multiply this value by 10
-3
and add to the other kVARh Net
parameters.
Represents
000,000,000,000. XXX kVARh
Default Value
0
Minimum Value
-999
Maximum Value
999
Parameter Type
INT
Size (Bytes)
2
Scaling Factor
1
Units
Default Value
0
Minimum Value
-999
Maximum Value
999
Parameter Type
INT
Size (Bytes)
2
Scaling Factor
1
Units
