Rockwell Automation Publication 193-UM015B-EN-P - June 2014 263
Metering and Diagnostics Chapter 7
kVAh 10
3
kVAh 10
3
(Parameter 102) reports a component of total apparent energy
(kVAh). Multiply this value by 10
3
and add to the other kVAh parameters.
Represents 000,000,XXX,000.000 kVAh
Table 307 - kVAh x 10E3 (Parameter 102)
kVAh 10
0
kVAh 10
0
(Parameter 103) reports a component of total apparent energy
(kVAh). Multiply this value by 10
0
and add to the other kVAh parameters.
Represents 000,000,000,XXX.000 kVAh
Table 308 - kVAh x 10E0 (Parameter 103)
kVAh 10
-3
kVAh 10
-3
(Parameter 104) reports a component of total apparent energy
(kVAh). Multiply this value by 10
-3
and add to the other kVAh parameters.
Represents 000,000,000,000. XXX kVAh
Table 309 - kVAh x 10E-3 (Parameter 104)
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
