Rockwell Automation Publication 193-UM015B-EN-P - June 2013 331
Appendix
B
Parameter List
Overview This appendix lists all accessible parameters of the E300™ overload relay in
numerical order.
The setting range for each parameter is provided to assist especially for
applications where it is desirable to set values from a logic controller via a network
connection.
Information values provided include the following:
Value Function
Setting Range Indicated as raw numerical values.
Scale Factor Indicate the decimal precision associated with each parameter. This must be given close attention
when writing or reading values.
Default Indicate the factory pre-programmed values.
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
Device Monitor 1 ThermUtilizedPct % Thermal Capacity Used USINT 1 1 0 100 0 %
2 OLTimeToTrip Time until an overload trip UINT 2 1 0 9999 0 Sec
3 OLTimeToReset Time until OL trip can be reset UINT 2 1 0 9999 0 Sec
4 TripStsCurrent Trip Status bits for Current UINT 2 1 Bit0= OverloadTrip
Bit1= PhaseLossTrip
Bit2= GroundFaultTrip
Bit3= StallTrip
Bit4= JamTrip
Bit5= UnderloadTrip
Bit6= CurrentImbalTrip
Bit7= L1UnderCurrTrip
Bit8= L2UnderCurrTrip
Bit9= L3UnderCurrTrip
Bit10= L1OverCurrenTrip
Bit11= L2OverCurrenTrip
Bit12= L3OverCurrenTrip
Bit13= L1LineLossTrip
Bit14= L2LineLossTrip
Bit15= L3LineLossTrip 0
5 TripStsVoltage Trip Status bits for Voltage UINT 2 1 Bit0= UnderVoltageTrip
Bit1= OvervoltageTrip
Bit2= VoltageUnbalTrip
Bit3= PhaseRotationTrp
Bit4= UnderFreqTrip
Bit5= OverFreqTrip 0
