Rockwell Automation Publication 193-UM015B-EN-P - June 2014 277
Metering and Diagnostics Chapter 7
Trip Snapshot Total Reactive Power
Trip Snapshot Total Reactive Power (Parameter 160) reports the total Reactive
power of the monitored power conductors in kVAR at the time of the most
recent trip event.
Table 330 - Trip Snapshot Total Reactive Power (Parameter 160)
Trip Snapshot Total Apparent Power
Trip Snapshot Total Apparent Power (Parameter 161) reports the total apparent
power of the monitored power conductors in kVA at the time of the most recent
trip event.
Table 331 - Trip Snapshot Total Apparent Power (Parameter 161)
Trip Snapshot Total Power Factor
Trip Snapshot Total Power Factor (Parameter 162) reports the total power factor
of the monitored power conductors in percentage at the time of the most recent
trip event.
Table 332 - Trip Snapshot Total Power Factor (Parameter 162)
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVAR or MVAR
Default Value 0.000
Minimum Value 0.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVA
Default Value 0.0
Minimum Value -100.0
Maximum Value 100.0
Parameter Type INT
Size (Bytes) 2
Scaling Factor 10
Units %
