Rockwell Automation Publication 193-UM015B-EN-P - June 2014 255
Metering and Diagnostics Chapter 7
kWh 10
3
kWh 10
3
(Parameter 82) reports a component of total real energy (kWh).
Multiply this value by 10
3
and add to the other kWh parameters.
Represents 000,000,XXX,000.000 kWh
Table 287 - kWh x 10E3 (Parameter 82)
kWh 10
0
kWh 10
0
(Parameter 83) reports a component of total real energy (kWh).
Multiply this value by 10
0
and add to the other kWh parameters.
Represents 000,000,000,XXX.000 kWh
Table 288 - kWh x 10E0 (Parameter 83)
kWh 10
-3
kWh 10
-3
(Parameter 84) reports a component of total real energy (kWh).
Multiply this value by 10
-3
and add to the other kWh parameters.
Represents 000,000,000,000. XXX kWh
Table 289 - kWh x 10E-3 (Parameter 84)
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
