378 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Appendix C EtherNet/IP Information
32
16
Language 4 212
OutAAssignment 4 202
OuBAssignment 4 203
OutCAssignment 4 204
33
InPt00Assignment 4 196
InPt01Assignment 4 197
InPt02Assignment 4 198
InPt03Assignment 4 199
34
17
InPt04Assignment 4 200
InPt05Assignment 4 201
ActFLA2wOutput 4 209
X EmergencyStartEn 4 216
X X X Reserved 4 NA
35
StartsPerHour 8 205
Reserved 8 NA
36
18
StartsInterval 16 206
37 PMTotalStarts 16 207
38
19
PMOperatingHours 16 208
39 FeedbackTimeout 16 213
40
20
TransitionDelay 16 214
41 InterlockDelay 16 215
42
21
GroundFaultType 8 241
GFInhibitTime 8 242
43
GFTripDelay 8 243
GFWarningDelay 8 245
44
22
GFTripLevel 16 244
45 GFWarningLevel 16 246
46
23
PLInhibitTime 8 239
PLTripDelay 8 240
47
StallEnabledTime 8 249
Reserved 8 NA
48
24
StallTripLevel 16 250
49
JamInhibitTime 8 251
JamTripDelay 8 252
50
25
JamTripLevel 16 253
51 JamWarningLevel 16 254
52
26
ULInhibitTime 8 255
ULTripDelay 8 256
53
ULTripLevel 8 257
ULWarningLevel 8 258
54
27
CIInhibitTime 8 259
CITripDelay 8 260
55
CITripLevel 8 261
CIWarningLevel 8 262
56
28
CTPrimary 16 263
57 CTSecondary 16 264
58
29
UCInhibitTime 8 265
L1UCTripDelay 8 266
59
L1UCTripLevel 8 267
L1UCWarningLevel 8 268
INT DINT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Size (bits) Param
