30

Rockwell Automation Publication 193-UM015B-EN-P - June 2014

Chapter 2 Installation and Wiring

Figure 16 - E300

Sensing Module 193-ESM-___-__-C55 with 100-C43…-C55 Contactor

Figure 17 - E300 Sensing Module 592-ESM-___-__-S2 with NEMA Contactor Size 0 and Size 1

54

(2.12)

45 (1.76)

190 (7.49)

107

(4.21)

60 (2.

45 (1.75)

n 5 (0.18)

37 (1.48)

34 (1.34)

122

(4.82)

152 (5.98)

67 (2.65)

FROM

CONTACTOR

MTG. HOLE

FROM

CONTACTOR

MTG. HOLE

(ADD 5 mm (0.19 in.)

FOR CONTACTOR COIL
ON LINE SIDE)

180 (7.06)

157 (6.17)

249 (9.78)

35 (1.38)

70

(2.75)

12 (0.46)

n 6 (0.22)

90

(3.56)

125

(4.91)
