Rockwell Automation Publication 193-UM015B-EN-P - June 2014 257
Metering and Diagnostics Chapter 7
kVARh Consumed 10
3
kVARh Consumed 10
3
(Parameter 87) reports a component of total reactive
energy consumed (kVARh). Multiply this value by 10
3
and add to the other
kVARh Consumed parameters.
Represents 000,000,XXX,000.000 kVARh
Table 292 - kVARh Consumed x 10E3 (Parameter 87)
kVARh Consumed 10
0
kVARh Consumed 10
0
(Parameter 88) reports a component of total reactive
energy consumed (kVARh). Multiply this value by 10
0
and add to the other
kVARh Consumed parameters.
Represents 000,000,000,XXX.000 kVARh
Table 293 - kVARh Consumed x 10E0 (Parameter 88)
kVARh Consumed 10
-3
kVARh Consumed 10
-3
(Parameter 89) reports a component of total reactive
energy consumed (kVARh). Multiply this value by 10
-3
and add to the other
kVARh Consumed parameters.
Represents 000,000,000,000. XXX kVARh
Table 294 - kVARh Consumed x 10E-3 (Parameter 89)
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
