Control module to sensing module assembly – Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 23
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
23
Installation and Wiring Chapter 2
Control Module to Sensing
Module Assembly
Any E300 Control Module can connect to any E300 Sensing Module. The
illustrations below show the steps required to make this connection.
Figure 6 - Control Module to Sensing Module Assembly\
2
3
1
