Rockwell Automation Publication 193-UM015B-EN-P - June 2014 121
Protective Trip and Warning Functions Chapter 5
L2 Over Current Trip Delay
L2 Over Current Trip Delay (Parameter 279) allows the installer to define the
time period a L2 Over Current condition must be present before a trip occurs. It
is adjustable from 0.1…25.0 seconds.
Table 107 - L2 Over Current Trip Delay (Parameter 279)
L2 Over Current Trip Level
L2 Over Current Trip Level (Parameter 280) allows the installer to define the
current at which the E300 Electronic Overload Relay will trip on a L2 Over
Current. It is user-adjustable from 10…100% of the FLA Setting (Parameter 171)
IMPORTANT The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Sec
