Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 337
Rockwell Automation Publication 193-UM015B-EN-P - November 2013
337
Parameter List Appendix B
Voltage Monitor
(Continued)
60
AvgVoltageLtoN
Average RMS Voltage Line-
Neutral
UINT
2
10
0
65535
0
Volt
61
VoltageUnbalance
Voltage Unbalance
USINT
1
1
0
255
0
%
62
VoltageFrequency
Voltage Frequency
UINT
2
10
0
2500
0
Hz
63
VPhaseRotation
Voltage Phase Rotation
(ABC or ACB)
UINT
2
1
0= NoRotation
1= ABC
2= ACB
0
Power Monitor
64
L1RealPower
Phase L1 Real Power.
DINT
4
1000
-2000000000 2000000000 0
kW
65
L2RealPower
Phase L2 Real Power.
DINT
4
1000
-2000000000 2000000000 0
kW
66
L3RealPower
Phase L3 Real Power.
DINT
4
1000
-2000000000 2000000000 0
kW
67
TotalRealPower
Total Real Power
DINT
4
1000
-2000000000 2000000000 0
kW
68
L1ReactivePower
Phase L1 Reactive Power
DINT
4
1000
-2000000000 2000000000 0
kVAR
69
L2ReactivePower
Phase L2 Reactive Power
DINT
4
1000
-2000000000 2000000000 0
kVAR
70
L3ReactivePower
Phase L3 Reactive Power
DINT
4
1000
-2000000000 2000000000 0
kVAR
71
TotalReactivePwr
Total Reactive Power
DINT
4
1000
-2000000000 2000000000 0
kVAR
72
L1ApparentPower
Phase L1 Apparent Power
DINT
4
1000
0
2000000000 0
kVA
73
L2ApparentPower
Phase L2 Apparent Power
DINT
4
1000
0
2000000000 0
kVA
74
L3ApparentPower
Phase L3 Apparent Power
DINT
4
1000
0
2000000000 0
kVA
75
TotalApparentPwr
Total Apparent Power
DINT
4
1000
0
2000000000 0
kVA
76
L1PowerFactor
Phase L1 True Power Factor (PF)
INT
2
10
-1000
1000
0
%
77
L2PowerFactor
Phase L2 True Power Factor (PF)
INT
2
10
-1000
1000
0
%
78
L3PowerFactor
Phase L3 True Power Factor (PF)
INT
2
10
-1000
1000
0
%
79
TotalPowerFactor
Total True Power Factor (PF)
INT
2
10
-1000
1000
0
%
Energy
Monitoring
80
kWhTimes10E9
Total Real Energy (kWh) Word
10^9
INT
2
1
-999
999
0
81
kWhTimes10E6
Total Real Energy (kWh) Word
10^6
INT
2
1
-999
999
0
82
kWhTimes10E3
Total Real Energy (kWh) Word
10^3
INT
2
1
-999
999
0
83
kWhTimes10E0
Total Real Energy (kWh) Word
10^0
INT
2
1
-999
999
0
84
kWhTimes10E-3
Total Real Energy (kWh) Word
10^-3
INT
2
1
-999
999
0
85
kVARhCon10E9
Total Reactive Energy Consumed
(kVARh) Word 10^9
INT
2
1
-999
999
0
86
kVARhCon10E6
Total Reactive Energy Consumed
(kVARh) Word 10^6
INT
2
1
-999
999
0
87
kVARhCon10E3
Total Reactive Energy Consumed
(kVARh) Word 10^3
INT
2
1
-999
999
0
88
kVARhCon10E0
Total Reactive Energy Consumed
(kVARh) Word 10^0
INT
2
1
-999
999
0
89
kVARhCon10E-3
Total Reactive Energy Consumed
(kVARh) Word 10^-3
INT
2
1
-999
999
0
90
kVARhGen10E9
Total Reactive Energy Generated
(kVARh) Word 10^9
INT
2
1
-999
999
0
91
kVARhGen10E6
Total Reactive Energy Generated
(kVARh) Word 10^6
INT
2
1
-999
999
0
92
kVARhGen10E3
Total Reactive Energy Generated
(kVARh) Word 10^3
INT
2
1
-999
999
0
93
kVARhGen10E0
Total Reactive Energy Generated
(kVARh) Word 10^0
INT
2
1
-999
999
0
94
kVARhGen10E-3
Total Reactive Energy Generated
(kVARh) Word 10^-3
INT
2
1
-999
999
0
Group
Param
No.
Parameter Name
Description
Type
Data Size
(bytes)
Scale
Factor
Min
Max
Default Units
