Rockwell Automation Publication 193-UM015B-EN-P - June 2014 421
EtherNet/IP Information Appendix C
The following common services are implemented.
Table 435 - E300 Status Object Common Services
26 Trip Snapshot
0
TS L1 Current
1
2
TS L2 Current
3
4
TS L3 Current
5
6
TS % TCU
7
8
TS GF Current
9
10
TS L1-L2 Voltage
11
12
TS L2-L3 Voltage
13
14
TS L3-L1 Voltage
15
16
TS Total Real Power
17
18
TS Total kVAR
19
20
TS Total kVA
21
22
TS Total PF
23
Attribute Name Byte Data
Service Code
Implemented for:
Service Name
Class Instance
0x03 No Yes Get_Attribute_List
0x0E No Yes Get_Attribute_Single
