Rockwell Automation Publication 193-UM015B-EN-P - June 2014 275
Metering and Diagnostics Chapter 7
Control Warning History Mask
Control Warning History Mask (Parameter 148) allows users to select which
control based warning events are recorded in the warning history.
Table 325 - Control Warning History Mask (Parameter 148)
Trip Snapshot Trip Snapshot L1-L2 Voltage
Trip Snapshot L1-L2 Voltage (Parameter 156) reports the voltage in volts in
reference to the T1 and T2 power terminals of the E300 Electronic Overload
Relay Sensing Module at the time of the most recent trip event.
Table 326 - Trip Snapshot L1-L2 Voltage (Parameter 156)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
Reserved
X PTC Warning
X DeviceLogix Warning
Reserved
Reserved
Reserved
Reserved
Reserved
X Option Match Warning
X Feedback Timeout Warning
X Expansion Bus Warning
X Number Of Starts Warning
X Operating Hours Warning
Reserved
Reserved
Reserved
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
