232
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Control Module ID
Control Module ID (Parameter 23) identifies which specific Control Module is
present in the E300 Electronic Overload Relay system.
Table 229 - Control Module ID (Parameter 23)
Sensing Module ID
Sensing Module ID (Parameter 24) identifies which specific Sensing Module is
present in the E300 Electronic Overload Relay system.
Table 230 - Sensing Module ID (Parameter 24)
Default Value
0
Range
0 = Unknown
1 = 193-EIO-63-24D
2 = 193-EIO-43-120
3 = 193-EIO-43-240
4 = 193-EIOGP-42-24D
5 = 193-EIOGP-22-120
6 = 193-EIOGP-22-240
Parameter Type
USINT
Size (Bytes)
1
Scaling Factor
1
Units
Default Value
0
Range
0 = Unknown
1 = 193/592-EIO-VIG-30A-__
2 = 193/592-EIO-VIG-60A-__
3 = 193/592-EIO-VIG-100A-__
4 = 193/592-EIO-VIG-200A-__
5 = 193/592-EIO-IG-30A-__
6 = 193/592-EIO-IG-60A-__
7 = 193/592-EIO-IG-100A-__
8 = 193/592-EIO-IG-200A-__
9 = 193/592-EIO-I-30A-__
10 = 193/592-EIO-I-60A-__
11 = 193/592-EIO-I-100A-__
12 = 193/592-EIO-I-200A-__
Parameter Type
USINT
Size (Bytes)
1
Scaling Factor
1
Units
