Rockwell Automation 592- E300 Overload Relay User Manual User Manual
Page 49
Rockwell Automation Publication 193-UM015B-EN-P - June 2014
49
Installation and Wiring Chapter 2
Figure 36 - CENELEC Nomenclature
Full-Voltage Reversing Starter (with Network Control)
Figure 37 - NEMA Nomenclature
L1
Relay 1
R13
R14
R03
R04
A1
A2
K
N
Relay 0 Configured
as a Trip Relay
2
2
Contact shown with supply voltage applied.
Relay 1
REV
Relay 2
FOR
FOR
REV
Relay 0 Configured as a
Trip Relay
1
1
Contact shown with supply voltage applied.
R13 R14
R23 R24
A1 A2
A1 A2
95 96
