356 Rockwell Automation Publication 193-UM015B-EN-P - November 2013
Appendix B Parameter List
Power Setup
(Continued)
378 UWInhibitTime Under Total Real Power Inhibit
Time USINT 1 1 0 250 10 Sec
379 UWTripDelay Under Total Real Power Trip Delay USINT 1 10 1 250 10 Sec
380 UWTripLevel Under Total Real Power Trip Level DINT 4 1000 0 2000000000 0 kW
381 UWWarningLevel Under Total Real Power Warning
Level DINT 4 1000 0 2000000000 0 kW
382 OWInhibitTime Over Total Real Power Inhibit
Time USINT 1 1 0 250 10 Sec
383 OWTripDelay Over Total Real Power Trip Delay USINT 1 10 1 250 10 Sec
384 OWTripLevel Over Total Real Power Trip Level DINT 4 1000 0 2000000000 0 kW
385 OWWarningLevel Over Total Real Power Warning
Level DINT 4 1000 0 2000000000 0 kW
386 UVARCInhibitTime Under Total Reactive Power
Consumed (+kVAR) Inhibit Time USINT 1 1 0 250 10 Sec
387 UVARCTripDelay Under Total Reactive Power
Consumed (+kVAR) Trip Delay USINT 1 10 1 250 10 Sec
388 UVARCTripLevel Under Total Reactive Power
Consumed (+kVAR) Trip Level DINT 4 1000 0 2000000000 0 kVAR
389 UVARCWarnLevel Under Total Reactive Power
Consumed (+kVAR) Warning
Level DINT 4 1000 0 2000000000 0 kVAR
390 OVARCInhibitTime Over Total Reactive Power
Consumed (+kVAR) Inhibit Time USINT 1 1 0 250 10 Sec
391 OVARCTripDelay Over Total Reactive Power
Consumed (+kVAR) Trip Delay USINT 1 10 1 250 10 Sec
392 OVARCTripLevel Over Total Reactive Power
Consumed (+kVAR) Trip Level DINT 4 1000 0 2000000000 0 kVAR
393 OVARCWarnLevel Over Total Reactive Power
Consumed (+kVAR) Warning
Level DINT 4 1000 0 2000000000 0 kVAR
394 UVARGInhibitTime Under Total Reactive Power
Generated (-kVAR) Inhibit Time USINT 1 1 0 250 10 Sec
395 UVARGTripDelay Under Total Reactive Power
Generated (-kVAR) Trip Delay USINT 1 10 1 250 10 Sec
396 UVARGTripLevel Under Total Reactive Power
Generated (-kVAR) Trip Level DINT 4 1000 -2000000000 0 0 kVAR
397 UVARGWarnLevel Under Total Reactive Power
Generated (-kVAR) Warning Level DINT 4 1000 -2000000000 0 0 kVAR
398 OVARGInhibitTime Over Total Reactive Power
Generated (-kVAR) Inhibit Time USINT 1 1 0 250 10 Sec
399 OVARGTripDelay Over Total Reactive Power
Generated (-kVAR) Trip Delay USINT 1 10 1 250 10 Sec
400 OVARGTripLevel Over Total Reactive Power
Generated (-kVAR) Trip Level DINT 4 1000 -2000000000 0 0 kVAR
401 OVARGWarnLevel Over Total Reactive Power
Generated (-kVAR) Warning Level DINT 4 1000 -2000000000 0 0 kVAR
402 UVAInhibitTime Under Total Apparent Power
Inhibit Time USINT 1 1 0 250 10 Sec
403 UVATripDelay Under Total Apparent Power Trip
Delay USINT 1 10 1 250 10 Sec
404 UVATripLevel Under Total Apparent Power Trip
Level DINT 4 1000 0 2000000000 0 kVA
405 UVAWarningLevel Under Total Apparent Power
Warning Level DINT 4 1000 0 2000000000 0 kVA
406 OVAInhibitTime Over Total Apparent Power Inhibit
Time USINT 1 1 0 250 10 Sec
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
