Product Overview Chapter 1
Catalog Number
Explanation E300 Electronic Overload Relay modules have their own catalog number. The
catalog numbers are explained below.
Sensing Module
Control Module
Communication Module
193 - ESM - VIG - 30A - C23
592
Module Type
ESM Sensing Module
Sensing Module Type
VIG Current, Ground Fault Current, 
Voltage, & Power

IG Current & Ground Fault Current 
I Current
Sensing Module Mounting Style
C23 Mounts to 100-C09…-C23 Contactor 
C55 Mounts to 100-C30…-C55 Contactor

C97 Mounts to 100-C60…-C97 Contactor

D180 Mounts to 100-D115…-D180 Contactor 
S2 Mounts to Bulletin 500 NEMA Size 0-2 Contactor

S3 Mounts to Bulletin 500 NEMA Size 3 Contactor 
S4 Mounts to Bulletin 500 NEMA Size 4 Contactor

T DIN Rail / Panel Mount with Power Terminals

E3T Replacement DIN Rail / Panel Mount with Power Terminals for an E3 Plus Panel Mount Adapter 
P DIN Rail / Panel Mount with Pass-thru Power Conductors

CT DIN Rail / Panel Mount with Pass-thru Power Conductors (used with External CTs)
Bulletin Number
193 IEC Overload Relay

592 NEMA Overload Relay
Sensing Current Range
30A 0.5…30 A 
60A 6…60 A

100A 10…100 A 
200A 20…200 A
193 - EIO - 43 - 120
Module Type
EIO I/O Only Control Module

EIOGP I/O and Protection Control Module 
(External Ground Fault Sensing

and PTC)
I/O Count
63 6 Inputs / 3 Relay Outputs

43 4 Inputs / 3 Relay Outputs 
42 4 Inputs / 2 Relay Outputs

22 2 Inputs / 2 Relay Outputs
Bulletin Number
193 IEC Overload Relay
Control Voltage
24D 24V DC

120 110…120V AC, 50/60 Hz 
240 220…240V AC, 50/60 H
193 - ECM - ETR
Module Type
ECM Communication Module
Communication Type
ETR EtherNet/IP with Dual Ethernet Ports

DNT DeviceNet
Bulletin Number
193 IEC Overload Relay
