Appendix B Parameter List
Device Monitor
(continued)
27
AnalogModuleID
Expansion Bus Analog Module
Types
UINT
2
1
Bit0= AnalogMod1[0]
Bit1= AnalogMod1[1]
Bit2= AnalogMod2[0]
Bit3= AnalogMod2[1]
Bit4= AnalogMod3[0]
Bit5= AnalogMod3[1]
Bit6= AnalogMod4[0]
Bit7= AnalogMod4[1]
0
28
OperatingTime
Time unit has been powered on
UINT
2
1
0
65535
0
Hrs
29
StartsCounter
Number of starts
UINT
2
1
0
65535
0
30
Starts Available
Number of Starts Available
USINT
1
1
0
120
0
31
TimeToStart
The Time to Start
UINT
2
1
0
3600
0
Sec
32
Year
Virtual RTC Year
UINT
2
1
0
9999
0
33
Month
Virtual RTC Month
UINT
2
1
0
12
0
34
Day
Virtual RTC Day
UINT
2
1
0
31
0
35
Hour
Virtual RTC Hour
UINT
2
1
0
23
0
36
Minute
Virtual RTC Minute
UINT
2
1
0
59
0
37
Second
Virtual RTC Second
UINT
2
1
0
59
0
38
InvaldCfgParam
Number of incorrectly configured
parameter
UINT
2
1
0
9999
0
39
InvaldCfgCause
Description of error
USINT
1
1
0=NoError
1=ValueOverMax
2=Value UnderMin
3=IllegalValue
4=L3CurrentDetected
5=CopyCat Error
6-50 = Reserved
0
40
Reserved
41
Reserved
42
Reserved
Current Monitor
43
L1Current
The actual L1 Phase Current.
DINT
4
100
0
2000000000 0
Amps
44
L2Current
The actual L2 Phase Current.
DINT
4
100
0
2000000000 0
Amps
45
L3Current
The actual L3 Phase Current.
DINT
4
100
0
2000000000 0
Amps
46
AverageCurrent
Average of Phase Currents.
DINT
4
100
0
2000000000 0
Amps
47
L1PercentFLA
L1 Current in %FLA
UINT
2
10
0
10000
0
%
48
L2PercentFLA
L2 Current in %FLA
UINT
2
10
0
10000
0
%
49
L3PercentFLA
L3 Current in %FLA
UINT
2
10
0
10000
0
%
50
AvgPercentFLA
Average Current in %FLA
UINT
2
10
0
10000
0
%
51
GFCurrent
The Ground Fault Current.
UINT
2
100
0
9999
0
Amps
52
CurrentImbal
Percent Current Imbalance
USINT
1
1
0
200
0
%
Voltage Monitor 53
L1toL2Voltage
3 Phase RMS Voltage Line-Line
UINT
2
10
0
65535
0
Volt
54
L2toL3Voltage
3 Phase RMS Voltage Line-Line
UINT
2
10
0
65535
0
Volt
55
L3toL1Voltage
3 Phase RMS Voltage Line-Line
UINT
2
10
0
65535
0
Volt
56
AvgVoltageLtoL
Average RMS Voltage Line-Line
UINT
2
10
0
65535
0
Volt
57
L1toNVoltage
3 Phase RMS Voltage Line-
Neutral
UINT
2
10
0
65535
0
Volt
58
L2toNVoltage
3 Phase RMS Voltage Line-
Neutral
UINT
2
10
0
65535
0
Volt
59
L3toNVoltage
3 Phase RMS Voltage Line-
Neutral
UINT
2
10
0
65535
0
Volt
Group
Param
No.
Parameter Name
Description
Type
Data Size
(bytes)
Scale
Factor
Min
Max
Default Units
