266 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Trip / Warning History The E300 Electronic Overload Relay provides a trip and warning history in
which the last five trips and last five warnings are recorded into non-volatile
storage. A mask is available to limit which trip and warning events are logged to
the history's memory.
Trip History
When the E300 Electronic Overload Relay issue a trip, the reason for the trip is
recorded into the Trip History. Listed below are the codes that are available for
the trip history records.
Table 316 - Trip History Codes
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVA
Trip History Code Description
0 No Fault Conditions Detected
1 Motor current overload condition
2 Phase current Loss detected in one of the motor phases
3 Power conductor or motor winding is shorting to ground
4 Motor has not reached full speed by the end of Stall Enable Time
5 Motor current has exceed the programmed jam trip level
6 Motor current has fallen below normal operating levels
7 Phase to phase current imbalance detected
8 L1Current was below L1 Undercurrent Level longer than Trip Delay
9 L2Current was below L2 Undercurrent Level longer than Trip Delay
10 L3Current was below L3 Undercurrent Level longer than Trip Delay
11 L1 Current was over L1 Overcurrent Level longer than Trip Delay
12 L2 Current was over L2 Overcurrent Level longer than Trip Delay
13 L3 Current was over L3 Overcurrent Level longer than Trip Delay
14 L1 Current Lost for longer than the L1 Loss Trip Delay
15 L2 Current Lost for longer than the L2 Loss Trip Delay
16 L3 Current Lost for longer than the L3 Loss Trip Delay
17 Line to Line Under-Voltage condition detected
18 Line to Line Over-Voltage condition detected
19 Phase to phase voltage imbalance detected
20 The unit detects the supply voltage phases are rotated
21 Line voltage frequency is below trip level
22 Line voltage frequency has exceeded trip level
25 Sensing Module boot loader failed to load firmware
