Rockwell Automation Publication 193-UM015B-EN-P - November 2013 333
Parameter List Appendix B
Device Monitor
(continued) 11 WarnStsVoltage Warning Status bits for Voltage UINT 2 1 Bit0= UnderVoltageWarn
Bit1= OvervoltageWarn
Bit2= VoltageUnbalWarn
Bit3= PhaseRotationWrn
Bit4= UnderFreqWarning
Bit5= OverFreqWarning 0
12 WarnStsPower Warning Status bits for Power UINT 2 1 Bit0= UnderKWWarning
Bit1= OverKWWarning
Bit2= UnderKVARConWarn
Bit3= OverKVARConWarn
Bit4= UnderKVARGenWarn
Bit5= OverKVARGenWarn
Bit6= UnderKVAWarning
Bit7= OverKVAWarning
Bit8= UnderPFLagWarn
Bit9= OverPFLagWarn
Bit10= UnderPFLeadWarn
Bit11= OverPFLeadWarn 0
13 WarnStsControl Warning Status bits for Control UINT 2 1 Bit0= Reserved
Bit1= PTCWarning
Bit2= DLXWarning
Bit3= Reserved
Bit4= Reserved
Bit5= Reserved
Bit6= Reserved
Bit7= ConfigWarning
Bit8= OptionMatchWarn
Bit9= DLXFBTimeoutWarn
Bit10= ExpansionBusWarn
Bit11= PMNumberOfStarts
Bit12= PMOperatingHours 0
14 WarnStsAnalog Warning Status bits for Analog UINT 2 1 Bit0= InAnMod1Ch00Warn
Bit1= InAnMod1Ch01Warn
Bit2= InAnMod1Ch02Warn
Bit3= InAnMod2Ch00Warn
Bit4= InAnMod2Ch01Warn
Bit5= InAnMod2Ch02Warn
Bit6= InAnMod3Ch00Warn
Bit7= InAnMod3Ch01Warn
Bit8= InAnMod3Ch02Warn
Bit9= InAnMod4Ch00Warn
Bit10= InAnMod4Ch01Warn
Bit11= InAnMod4Ch02Warn 0
15 Reserved
16 InputStatus0 Status of Digital Inputs UINT 2 1 Bit0= InputPt00
Bit1= InputPt01
Bit2= InputPt02
Bit3= InputPt03
Bit4= InputPt04
Bit5= InputPt05 0
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
