Rockwell Automation Publication 193-UM015B-EN-P - June 2014 189
Protective Trip and Warning Functions Chapter 5
Under Power Factor Leading Trip Delay
Under Power Factor Leading Trip Delay (Parameter 419) allows the installer to
define the time period an under power factor leading condition must be present
before a trip occurs. It is adjustable from 0.1…25.0 seconds.
Table 190 - Under Power Factor Leading Trip Delay (Parameter 419)
Under Power Factor Leading Trip Level
Under Power Factor Leading Trip Level (Parameter 420) allows the installer to
define the power factor leading at which the E300 Electronic Overload Relay will
trip on an under power factor leading. It is user-adjustable from 0…2,000,000
kW.
IMPORTANT The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Sec
