Metering and Diagnostics Chapter 7
Current Trip Status
Current Trip Status (Parameter 4) reports the status of the current based
protective trip functions.
Table 214 - Current Trip Status (Parameter 4)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Overload Trip
X
Phase Loss Trip
X
Ground Fault Current Trip
X
Stall Trip
X
Jam Trip
X
Underload Trip
X
Current Imbalance Trip
X
L1 Under Current Trip
X
L2 Under Current Trip
X
L3 Under Current Trip
X
L1 Over Current Trip
X
L2 Over Current Trip
X
L3 Over Current Trip
X
L1 Line Loss Trip
X
L2 Line Loss Trip
X
L3 Line Loss Trip
