126 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 5 Protective Trip and Warning Functions
Table 113 - Line Loss Inhibit Time (Parameter 285)
L1 Line Loss Trip
The E300 Electronic Overload Relay will trip with a L1 Line Loss indication if:
• No trip currently exists
• L1 Over Current Trip is enabled
• L1 Line Loss is activated via the appropriately programmed digital input
(see Input Assignments, Parameters 196-201, in Chapter 3)
• Line Loss Inhibit Timer has expired
• L1 Percent FLA (Parameter 47) is
• equal to 0% for a time period greater than the L1 Line Loss Trip Delay.
If the E300 Electronic Overload Relay trips on a L1 Line Loss, the:
• TRIP/WARN LED status indicator will flash a red 14-short blink pattern
• Bit 13 in Current Trip Status (Parameter 4) will set to 1
• Bit 0 in Device Status 0 (Parameter 20) will set to 1
• Any relay outputs configured as a Trip Relay will open
• Any relay outputs configured as a Control Relay will open
• Any relay outputs configured as a Trip Alarm will close
• Any relay outputs configured as a Normal Relay will be placed in their
Protection Fault state (if so programmed)
Default Value 10
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Sec
