Metering and Diagnostics Chapter 7
Table 317 - Current Trip History Mask (Parameter 139)
Voltage Trip History Mask
Voltage Trip History Mask (Parameter 140) allows users to select which voltage
based trip events are recorded in the trip history.
Table 318 - Voltage Trip History Mask (Parameter 140)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Overload Trip
X
Phase Loss Trip
X
Ground Fault Trip
X
Stall Trip
X
Jam Trip
X
Underload Trip
X
Current Imbalance Trip
X
L1 Under Current Trip
X
L2 Under Current Trip
X
L3 Under Current Trip
X
L1 Over Current Trip
X
L2 Over Current Trip
X
L3 Over Current Trip
X
L1 Line Loss Trip
X
L2 Line Loss Trip
X
L3 Line Loss Trip
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Under Voltage Trip
X
Over Voltage Trip
X
Voltage Imbalance Trip
X
Phase Rotation Trip
X
Under Frequency Trip
X
Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
