Protective Trip and Warning Functions Chapter 5
Control Trip Status (Parameter 7) and Control Warning Status (Parameter 13)
are used to monitor the respective current based protective trip and warning
functions.
Table 197 - Control Warning Enable (Parameter 192)
Table 198 - Control Trip Status (Parameter 7)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
Reserved
Reserved
X
DeviceLogix Warning Enable
X
Operator Station Warning Enable
Reserved
Reserved
Reserved
Reserved
X
Option Match Warning Enable
X
Feedback Timeout Warning Enable
X
Expansion Bus Warning Enable
X
Number Of Starts Warning Enable
X
Operating Hours Warning Enable
Reserved
Reserved
Reserved
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Test Trip
X
PTC Trip
X
DeviceLogix Trip
X
Operator Station Trip
X
Remote Trip
X
Blocked Start Trip
X
Hardware Fault Trip
X
Configuration Trip
X
Option Match Trip
X
Feedback Timeout Trip
X
Expansion Bus Trip
Reserved
Reserved
X
Non-Volatile Memory Trip
X
Test Mode Trip
Reserved
