background image

56

Rockwell Automation Publication 193-UM015B-EN-P - June 2014

Chapter 3 System Operation and Configuration

Enable Option Match Protection Warning (Parameter 192)

To enable the E300 Electronic Overload Relay’s Option Match feature to cause a
warning in the event of an option mismatch, place a (1) in bit position 8 of
Parameter 192 (Control Warning Enable). Users can select the specific option
match features to cause a warning in Parameter 233 (Option Match Action).

Table 24 - Enable Option Match Protection Warning Bit Function Detail— Control Warning
Enable (Parameter 192)

Control Module Type (Parameter 221)

The E300 Electronic Overload Relay offers six different control modules. Place
the value of the expected control module into Parameter 221. A value of (0)
disables the Option Match feature for the control module.

Table 25 - Control Module Type (Parameter 221)

Bit

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

Function

Reserved

Reserved

X

DeviceLogix Warning Enable

Reserved

Reserved

Reserved

Reserved

Reserved

X

Option Match Warning Enable

X

Feedback Timeout Warning Enable

X

Expansion Bus Warning Enable

X

Number Of Starts Warning Enable

X

Operating Hours Warning Enable

Reserved

Code

Description

Control Module Cat. No.

0

Ignore

1

6 Inputs, 24V DC / 3 Relay Outputs

193-EIO-63-24D

2

4 Inputs, 110-120V AC 50/60Hz / 3 Relay Outputs

193-EIO-43-120

3

4 Inputs, 220-240V AC 50/60Hz / 3 Relay Outputs

193-EIO-43-240

4

4 Inputs, 24V DC / 2 Relay Outputs / External Ground Fault / PTC

193-EIOGP-42-24D

5

2 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC

193-EIOGP-22-120

6

2 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC

193-EIOGP-22-240
