Protective Trip and Warning Functions Chapter 5
Table 118 - Voltage Trip Enabled (Parameter 184)
Table 119 - Voltage Warning Enable (Parameter 190)
Voltage Trip Status (Parameter 5) and Voltage Warning Status (Parameter 11) are
used to view the status of the respective voltage based protective trip and warning
functions.
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X Under Voltage Trip
X Over Voltage Trip
X Voltage Imbalance Trip
X Phase Rotation Mismatch Trip
X Under Frequency Trip
X Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X Under Voltage Warning
X Over Voltage Warning
X Voltage Imbalance Warning
X Phase Rotation Mismatch Warning
X Under Frequency Warning
X Over Frequency Warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
