370 Rockwell Automation Publication 193-UM015B-EN-P - November 2013
Appendix B Parameter List
Analog4 Setup
(continued)
558 OutAnMod4Select Assignment of parameter data
value to drive Analog Module 4
Output USINT 1 1 0= AveragePctFLA
1= ScaledAvgPctFLA
2= PercentTCU
3= GFCurrent
4= CurrentUnbalance
5= AvgLLVoltage
6=VoltLLUnbalance
7= TotalkW
8= TotalkVA
9= TotalkVAR
10= TotalPF
11= UserDLXData 0
559 OutAnMod4FltActn Analog Module 4 Output action
on comms fault USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= HoldLastState 0
560 OutAnMod4IdlActn Analog Module 4Output action
on comms idle USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= HoldLastState 0
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
