34 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 2 Installation and Wiring
Terminals Sensing Module
Table 1 - E300 Sensing Module Wire Size and Torque Specifications
Wire Type Conductor Torque
Cat. No.
193-ESM-_ _ _-30A-_ _ _
193-ESM-_ _ _-60A-_ _ _
592-ESM-_ _ _-30A-_ _ _
592-ESM-_ _ _-60A-_ _ _
193-ESM-_ _ _-100A-_ _ _
592-ESM-_ _ _-100A-_ _ _
Stranded/Solid [AWG]
Single
#14…6 AWG
22 lb-in. #12…1 AWG
35 lb-in.
Multiple
#10…6 AWG
30 lb-in. #6…2 AWG
35 lb-in.
Flexible-Stranded with Ferrule Metric
Single
2.5…16 mm2
2.5 N•m 4…35 mm2
4 N•m
Multiple
6…10 mm2
3.4 N•m 4…25 mm2
4 N•m
Coarse-Stranded/Solid Metric
Single
2.5…25 mm2
2.5 N•m 4…50 mm2
4 N•m
Multiple
6…16 mm2
3.4 N•m 4…35 mm2
4 N•m
