CHAPTER 2 CPU
2.8-1 . DPR is eight bits long, and is initialized to 01
H
by a reset. DPR can be read or written to by an
instruction.
Figure 2.8-1 Generating a Physical Address in Direct Addressing Mode
●
Program counter bank register (PCB)
●
Data bank register (DTB)
H
>
●
User stack bank register (USB)
H
>
●
System stack bank register (SSB)
H
>
●
Additional data bank register (ADB)
H
>
Each bank register indicates the memory bank where the PC, DT, SP (user), SP (system), or AD space is
allocated. All bank registers are one byte long. PCB is initialized to 00
H
by a reset. Bank registers other
than PCB can be read or written to. PCB can be read but cannot be written to.
PCB is updated when the JMPP, CALLP, RETP, RETIQ, or RETF instruction branching to the entire 16M
bytes space is executed or when an interrupt occurs. For operation of each register, see "2.2 Memory
Space".
α α α α α α α α β β β β β β β β γ γ γ γ γ γ γ γ
α α α α α α α α β β β β β β β β γ γ γ γ γ γ γ γ
MSB LSB
DTB register DPR register
Direct address during instruction
24-bit physical address
