CHAPTER 7 RESETS

stabilization wait time has elapsed, the reset is executed.

External reset

An external reset is generated by the L level input to an external reset pin (RST pin). The minimum

required period of the L level is at least 500 ns. Reset operation is performed after oscillation stabilization

wait time elapses.

Note:

If the reset cause is generated during a write operation, the CPU waits for the reset to be cleared after

completion of the instruction only for reset requests via the RST pin. Therefore, the normal write

operation is completed even though a reset is inputted concurrently. However, note that the following two

points.

Note that a reset may prevent the data transfer requested by a string-processing instruction from being

completed because the reset is accepted before a specified number of counters are transferred.

At external bus access, if the cycle is exceeded a certain period by RDY input, the reset is accepted

forcibly without waiting the completion of instruction. Forcible reset is accepted within 16 machine

cycles.

When returning to the main clock mode by the external reset pin (RST pin) from the stop mode, sub-

clock mode, sub-sleep mode, and watch mode, input L level for at least oscillation time of oscillator* +

100

µs.

*: Oscillation time of oscillator is the time that amplitude reaches 90%. It takes several to dozens of ms

for crystal oscillators, hundreds of

µs to several ms for FAR/ceramic oscillators, and 0 ms for external

clocks.

When returning to the main clock mode by the external reset pin (RST pin) from the timebase timer

mode, input L level for at least 100

µs.

Software reset

A software reset is generated an internal reset by writing "0" to the RST bit of the low-power consumption

mode control register (LPMCR). The oscillation stabilization wait time is not required for a software reset.

Watchdog reset

A watchdog reset is generated by a watchdog timer overflow that occurs when "0" is not written to the

WTE bit of the watchdog timer control register (WDTC) within a given time after the watchdog timer is

activated. The oscillation stabilization wait time is not required for watchdog reset.

Low voltage detection reset

The low voltage detection reset is generated when the low voltage (4.0 V

± 0.3 V) is detected.

The oscillation stabilization wait time is not required for the low voltage detection reset.
