471
21.4.15 Transmission Complete Register (TCR)
At completion of transmission by the message buffer (x), the corresponding TCx
becomes 1.
If TIEx of the transmission complete interrupt enable register (TIER) is 1, an interrupt
occurs.
■ Register Configuration
Figure 21.4-15 Configuration of the Transmission Complete Register (TCR)
■ Register Function
●
Conditions for TCx = 0
• Write 0 to TCx.
• Write 1 to TREQx of the transmission request register (TREQR).
After the completion of transmission, write 0 to TCx to set it to 0. Writing 1 to TCx is ignored.
1 is read when a Read Modify Write instruction is performed.
Note:
If setting to 1 by completion of the transmit operation and clearing to 0 by writing occur at the same
time, the bit is set to 1.
Address bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 TCR1(Upper)
CAN1: 000087 H TC15 TC14 TC13 TC12 TC11 TC10 TC9 TC8 Reset value
0 0 0 0 0 0 0 0
B
R/W R/W R/W R/W R/W R/W R/W R/W
Address bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 TCR1(Lower)
CAN1: 000086 H TC7 TC6 TC5 TC4 TC3 TC2 TC1 TC0 Reset value
0 0 0 0 0 0 0 0
B
R/W R/W R/W R/W R/W R/W R/W R/W
R/W : Read/Write
X : Undefined
