407

CHAPTER 20 LIN-UART

Reception Interrupt

If one of the following events occurs in reception mode, the corresponding flag bit of the serial status

register (SSR) is set to "1":

Data reception is completed, i. e. the received data was transferred from the serial input shift register to

the reception data register (RDR) and data can be read: RDRF

Overrun error, i. e. RDRF = 1 and RDR was not read by the CPU and next serial data is received: ORE

Framing error, i. e. a stop bit was expected, but a "0"-bit was received: FRE

Parity error, i. e. a wrong parity bit was detected: PE

If at least one of these flag bits above go "1" and the reception interrupt is enabled (SSR: RIE = 1), a

reception interrupt request is generated.

If the reception data register (RDR) is read, the RDRF flag is automatically cleared to "0". The error flags

are cleared to "0", if a "1" is written to the clear reception error (CRE) flag bit of the serial control register

(SCR).

Note:

The CRE flag is "write only" and by writing a "1" to it, it is internally held to "1" for one clock cycle.

Transmission Interrupt

If transmission data is transferred from the transmission data register (TDR) to the transfer shift register

and transfer is started, the transmission data empty flag bit (TDRE) of the serial status register (SSR) is set

to "1". In this case an interrupt request is generated, if the transmission interrupt enable (TIE) bit of the

SSR was set to "1" before.

Note:

The initial value of TDRE (after hardware or software reset) is "1". So an interrupt is generated

immediately then, if the TIE flag is set to "1". Also note, that the only way to reset the TDRE flag is

writing data to the transmission data register (TDR).

LIN Synchronization Break Interrupt

This paragraph is only relevant, if LIN-UART operates in mode 3 as a LIN slave.

If the bus (serial input) goes "0" (dominant) for more than 11 bit times, the LIN synch break detected

(LBD) flag bit of the extended status/control register (ESCR) is set to "1". Note, that in this case after 9 bit

times the reception error flags are set to "1", therefore the RXE flag has to set to "0", if only a LIN synch

break detect is desired.

The LIN synch break interrupt and the LBD flag are cleared after writing a "0" to the LBD flag. The LBD

flag has to be performed before input capture interrupt for LIN synch field.

When LIN synch break detection is performed, it is necessary to disable the reception (SCR: RXE=0).
