FUJITSU F2MCTM-16LX - Manual (Page 467)

451
■ List of Message Buffer (data register)
Table 21.3-4 List of Message Buffer (data register)
Address
Register Abbreviation Access Initial Value
CAN1
007C80
H
to
007C87
H
Data register 0
(8 bytes)
DTR0 R/W
XXXXXXXX to
XXXXXXXX
007C88
H
to
007C8F
H
Data register 1
(8 bytes)
DTR1 R/W
XXXXXXXX to
XXXXXXXX
007C90
H
to
007C97
H
Data register 2
(8 bytes)
DTR2 R/W
XXXXXXXX to
XXXXXXXX
007C98
H
to
007C9F
H
Data register 3
(8 bytes)
DTR3 R/W
XXXXXXXX to
XXXXXXXX
007CA0
H
to
007CA7
H
Data register 4
(8 bytes)
DTR4 R/W
XXXXXXXX to
XXXXXXXX
007CA8
H
to
007CAF
H
Data register 5
(8 bytes)
DTR5 R/W
XXXXXXXX to
XXXXXXXX
007CB0
H
to
007CB7
H
Data register 6
(8 bytes)
DTR6 R/W
XXXXXXXX to
XXXXXXXX
007CB8
H
to
007CBF
H
Data register 7
(8 bytes)
DTR7 R/W
XXXXXXXX to
XXXXXXXX
007CC0
H
to
007CC7
H
Data register 8
(8 bytes)
DTR8 R/W
XXXXXXXX to
XXXXXXXX
007CC8
H
to
007CCF
H
Data register 9
(8 bytes)
DTR9 R/W
XXXXXXXX to
XXXXXXXX
007CD0
H
to
007CD7
H
Data register 10
(8 bytes)
DTR10 R/W
XXXXXXXX to
XXXXXXXX
007CD8
H
to
007CDF
H
Data register 11
(8 bytes)
DTR11 R/W
XXXXXXXX to
XXXXXXXX
007CE0
H
to
007CE7
H
Data register 12
(8 bytes)
DTR12 R/W
XXXXXXXX to
XXXXXXXX
007CE8
H
to
007CEF
H
Data register 13
(8 bytes)
DTR13 R/W
XXXXXXXX to
XXXXXXXX
007CF0
H
to
007CF7
H
Data register 14
(8 bytes)
DTR14 R/W
XXXXXXXX to
XXXXXXXX
007CF8
H
to
007CFF
H
Data register 15
(8 bytes)
DTR15 R/W
XXXXXXXX to
XXXXXXXX
