FUJITSU F2MCTM-16LX User Manual
Page 623
607
APPENDIX B Instructions
Note:
See Table B.5-1 and Table B.5-2 for information on (a) to (d) in the table.
Note:
See Table B.5-1 and Table B.5-2 for information on (a) to (d) in the table.
Table B.8-9 6 Logic 2 Instructions (long word)
Mnemonic
#
RG
B
Operation
L
H
A
H
I
S
T
N
Z
V
C
R
M
W
ANDL
A,ear
2
6
2
0
long (A) <-- (A) and (ear)
-
-
-
-
-
*
*
R
-
-
ANDL
A,eam
2+
7+(a)
0
(d)
long (A) <-- (A) and (eam)
-
-
-
-
-
*
*
R
-
-
ORL
A,ear
2
6
2
0
long (A) <-- (A) or (ear)
-
-
-
-
-
*
*
R
-
-
ORL
A,eam
2+
7+(a)
0
(d)
long (A) <-- (A) or (eam)
-
-
-
-
-
*
*
R
-
-
XORL
A,ear
2
6
2
0
long (A) <-- (A) xor (ear)
-
-
-
-
-
*
*
R
-
-
XORL
A,eam
2+
7+(a)
0
(d)
long (A) <-- (A) xor (eam)
-
-
-
-
-
*
*
R
-
-
Table B.8-10 6 Sign Inversion Instructions (byte, word)
Mnemonic
#
RG
B
Operation
L
H
A
H
I
S
T
N
Z
V
C
R
M
W
NEG
A
1
2
0
0
byte (A) <-- 0 - (A)
X
-
-
-
-
*
*
*
*
-
NEG
ear
2
3
2
0
byte (ear) <-- 0 - (ear)
-
-
-
-
-
*
*
*
*
-
NEG
eam
2+
5+(a)
0
2 x (b)
byte (eam) <-- 0 - (eam)
-
-
-
-
-
*
*
*
*
*
NEGW
A
1
2
0
0
word (A) <-- 0 - (A)
-
-
-
-
-
*
*
*
*
-
NEGW
ear
2
3
2
0
word (ear) <-- 0 - (ear)
-
-
-
-
-
*
*
*
*
-
NEGW
eam
2+
5+(a)
0
2 x (c)
word (eam) <-- 0 - (eam)
-
-
-
-
-
*
*
*
*
*
Table B.8-11 1 Normalization Instruction (long word)
Mnemonic
#
RG
B
Operation
L
H
A
H
I
S
T
N
Z
V
C
R
M
W
NRML
A,R0
2
*1
1
0
long (A) <-- Shifts to the position where '1' is set for
the first time.
byte (RD) <-- Shift count at that time
-
-
-
-
-
-
*
-
-
-
*1: 4 when all accumulators have a value of 0; otherwise, 6+(R0)
