CHAPTER 21 CAN CONTROLLER
21.4.16 Transmission Interrupt Enable Register (TIER)
This register enables or disables the transmission interrupt by the message buffer (x).
The transmission interrupt is generated at transmission completion (when TCx of the
transmission complete register (TCR) is 1).
■ Register Configuration
Figure 21.4-16 Configuration of the Transmission Interrupt Enable Register (TIER)
■ Register Function
0: Transmission interrupt disabled.
1: Transmission interrupt enabled.
Address bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 TIER1(Upper)
CAN1: 007D0F H TIE15 TIE14 TIE13 TIE12 TIE11 TIE10 TIE9 TIE8 Reset value
0 0 0 0 0 0 0 0
B
R/W R/W R/W R/W R/W R/W R/W R/W
Address bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 TIER1(Lower)
CAN1: 007D0E H TIE7 TIE6 TIE5 TIE4 TIE3 TIE2 TIE1 TIE0 Reset value
0 0 0 0 0 0 0 0
B
R/W R/W R/W R/W R/W R/W R/W R/W
R/W : Read/Write
