304
CHAPTER 16 8-/16-BIT PPG TIMER
16.5.2
16-bit PPG Output Operation Mode
In the 16-bit PPG output operation mode, the 8-/16-bit PPG timer is set as a 16-bit PPG
timer with one channel.
■
Setting for 16-bit PPG Output Operation Mode
Operating the 8-/16-bit PPG timer in the 16-bit PPG output operation mode requires the setting shown in
Figure 16.5-4 Setting for 16-bit PPG Output Operation Mode
Note:
Use a long-word instruction to set the values in the PPG reload registers or a word instruction to set the
PPGn and PPGm (PRLLn --> PRLLm or PRLHn --> PRLHm) in this order.
PIE1 PUF1
MD0
MD1
PEN1
−
PE1
PPGCm/PPGCn
1
1
1
1
1
PIE0 PUF0
−
−
PEN0
−
PE0
PPGnm
PCM2 PCM1
−
REV
PCM0
PCS2 PCS1 PCS0
bit15 14
13
12
11
10
9
bit8 bit7
6
5
4
3
2
1
bit0
PRLHn/PRLLn
PRLHm/PRLLm
1
Re-
served
(Reserved area)
Re-
served
PPGn set high level side reload values of lower
8 bits.
PPGn set low level side reload values of lower
8 bits.
PPGm set high level side reload values of upper
8 bits.
PPGm set low level side reload values of upper
8 bits.
: Used bit
✕
: Unused bit
-
: Undefined bit
1 : Set 1
0 : Set 0
Note: n = C, E
m = n + 1
