490
CHAPTER 21 CAN CONTROLLER
21.6 Reception of CAN Controller
Reception starts when the start of data frame or remote frame (SOF) is detected on the
CAN bus.
■ Acceptance Filtering
The received message in the standard frame format is compared with the message buffer (x) set in the
standard frame format (IDEx of the IDE register (IDER) is 0). The received message in the extended frame
format is compared with the message buffer (x) set (IDEx is 1) in the extended frame format.
If all the bits set to Compare by the acceptance mask agree after comparison between the received message
ID and acceptance code (ID register (IDRx) for comparing with the received message ID), the received
message passes to the acceptance filter of the message buffer (x).
■ Storing Received Message
When the receive operation is successful, received messages are stored in a message buffer x including IDs
passed through the acceptance filter.
When receiving data frames, received messages are stored in the ID register (IDRx), DLC register
(DLCRx), and data register (DTRx).
Even if received message data is less than 8 bytes, some data is stored in the remaining bytes of the DTRx
and its value is undefined.
When receiving remote frames, received messages are stored only in the IDRx and DLCRx, and the DTRx
remains unchanged.
If there is more than 1 message buffer including IDs passed through the acceptance filter, the message
buffer x in which received messages are to be stored is determined according to the following rules.
• The order of priority of the message buffer x (x = 0 to 15) rises as its number lower; in other words,
message buffer 0 is given the highest and the message buffer 15 is given the lowest priority.
• Basically, message buffers with the RCx bit of 0 in the receive completion register (RCR) are preferred
in storing received messages.
• If the bits of the acceptance mask select register (AMSR) are set to All Bits Compare (for message
buffers with the AMSx.1 and AMSx.0 bits set to 00
B
), received messages are stored irrespective of the
value of the RCx bit of the RCR.
• If there are message buffers with the RCx bit of the RCR set to 0, or with the bits of the AMSR set to
All Bits Compare, received messages are stored in the lowest-number (highest-priority) message buffer
x.
• If there are no message buffers above-mentioned, received messages are stored in a lower-number
message buffer x.
• Message buffers should be arranged in ascending numeric order. The lowest message buffers should be
with All Bits Compare, then AMR0 or AMR1 masks. And The highest message buffers should be with
All Bits Mask.
