CHAPTER 13 16-Bit I/O TIMER
■ Details of Pins and Interrupt Number
Table 13.2-1 shows the pins used by the 16-bit details of interrupt.
Table 13.2-1 Details of Pins and Interrupt Number
Channel Special
terminal
Pin name Interrupt
No.
For
I
2
OS
Input capture ch0 (using 16-bit free-run timer ch0) IN0 P24/IN0 #33
(21
H
)
❍
Input capture ch1 (using 16-bit free-run timer ch0) IN1 P25/IN1
Input capture ch2 (using 16-bit free-run timer ch0) IN2 P26/IN2
Input capture ch3 (using 16-bit free-run timer ch0) IN3 P27/IN3
16-bit free-run timer ch0 (overflow interrupt) FRCK0 P44/FRCK0 #30
(1E
H
)
✕
