12
CHAPTER 1 OVERVIEW
1.3 Package Dimensions
MB90360 series has a package.
Note that the dimensions show below are reference dimensions. For formal dimensions
of each package, contact us.
■ Package Dimensions
Figure 1.3-1 shows the package dimensions of LQFP-48 type.
Figure 1.3-1 Package Dimensions of LQFP-48 Type
48-pin plastic LQFP Lead pitch 0.50 mm
Package width ×
package length
7 × 7 mm
Lead shape Gullwing
Sealing method Plastic mold
Mounting height 1.70 mm MAX
Weight 0.17 g
Code
(Reference)
P-LFQFP48-7 ×7-0.50
48-pin plastic LQFP
(FPT-48P-M26)
(FPT-48P-M26)
C 2003 FUJITSU LIMITED F48040S-c-2-2
24
13
36 25
48
37
INDEX
SQ
9.00±0.20(.354±.008)SQ
0.145±0.055
(.006±.002)
0.08(.003)
"A"
0˚~8˚
.059 –.004
+.008
–0.10
+0.20
1.50
0.60±0.15
(.024±.006)
0.10±0.10
(.004±.004)
(Stand off)
0.25(.010)
Details of "A" part
1 12
0.08(.003) M
(.008±.002)
0.20±0.05
0.50(.020)
LEAD No.
(Mounting height)
.276 –.004
+.016
–0.10
+0.40
7.00 *
Dimensions in mm (inches).
Note: The values in parentheses are reference values.
Note 1) * : These dimensions include resin protrusion.
Note 2) Pins width and pins thickness include plating thickness.
Note 3) Pins width do not include tie bar cutting remainder.
